Réducteur de pression réglable à brides DN50-DN65

Adjustable pressure reducer with flanges DN50-DN65

130036
Delivery 8 to 12 days
€1,048.33

€1,048.33 tax excl.

DN50-DN65 pressure reducer and regulator, PN10/16 flanged connection, adjustable from 1 to 7.5 bar, max inlet pressure 25 bar, use on cold water and hot water networks, max 80 °C.

Model

Attributs
Image Ref. Model Unit price Avail. Buy
Adjustable pressure reducer with flanges DN50-DN65
130036 DN 50
€1,048.33
Available
Adjustable pressure reducer with flanges DN50-DN65
130037 DN 65
€1,221.67
Available
Total: 0,0
All prices with tax included.
Available Product is available
Out of stock Product is no longer in stock
Can be back-ordered Product is no in stock, but is allowed to be back-ordered
Description

Specifications:
- Piston pressure reducer.
- Bronze body.
- Internal parts in brass.
- 303 stainless steel seat.
- NBR 70 O-ring seal.
- Flanged connection PN10/16 EN 1092-3-4.
- Max. water temperature 80°C.
- Supplied with pressure gauges.
- Sanitary Conformity Certificate (ACS, WRAS and DVGW).

Model DN50 DN65
Reference 130036 130037
Maximum inlet pressure (bar)
 30
Adjustable (bar) 1 to 7.5
Pressure gauge port (BSP) 1/4"
L (mm) 164 147
H (mm) 250 260
Weight (Kg) 10.7 10.5
