Applications:
- Automatic drinking water supply pump for chalets, remote sites, motorhomes, boating, mobile homes, lorries, 4x4s, etc.
Specifications:
- Nickel-plated brass body and fittings.
- 316 stainless steel shaft.
- PTFE helical gears.
- Check valve.
- Horizontal diaphragm tank 60L.
- Electronic control of the motor speed according to the flow rate.
- 12-24 or 24 volt DC power supply, depending on model.
- The assembly is assembled, glued and connected by us.
- Hydraulic pressure tested and adjusted in the workshop.
- Supplied with PCS control box, with connector, 3 m cable, (allows remote monitoring of the pump operation and interaction with it). (Model G-UP6/E + PCS).
| Models | G-UP12/E 12-24-PCS |
G-UP12/E 24-PCS |
|---|---|---|
| Reference | 605635 | 605636 |
| Supply (V DC) | 12-24 | 24 |
| Power (W) | 360 | |
| Consumption (A) |
15 | 15 |
| Fuse (A) | 25 | 15 |
| PCS box | WITH | WITH |
| Flow rate (l/min) | 0 to 36 | |
| Pressure (bar) | 2.5 | 3.5 |
| Priming (m) | -3 | |
| Ports | 1/2" | |
| Hose (mm) | 16 | |
| Max. liquid temperature (°C) |
40 | |
| Protection rating | IP67 | |
| Dimensions (mm) Height x Length x Width |
670 x 675 x 420 | |
| Weight (Kg) | 22.0 | |
