Specifications:
- Motor frame and pump body in B10 bronze.
- Vortex impeller in B10 bronze.
- Shaft and suction strainer in 316 stainless steel.
- Sealed by two silicon carbide mechanical seals (2SIC), lubricated in an oil chamber.
- VITON gaskets.
- Max operating temperature 40 °C.
- pH between 5 and 11.
- Viscosity of the treated liquid 1 mm²/s.
- Max immersion depth 20 metres.
- Liquid density 1.1 Kg/m3.
- Noise 70 dB.
- Max starts per hour = 30.
- 2-year warranty.
- IP 68 - Insulation class F.
- Duty: S1 continuous use.
- Cable length 10 m.
- On/Off float switch + starter panel.
| Model | DGB 75/2/G50V M/A |
DGB 150/2/G50V M/A |
|---|---|---|
| Reference | 210580 | 210581 |
| Power (Kw) | 0.55 | 1.10 |
| Current (A) | 3.9 | 8.2 |
| Voltage (V) | 230 single-phase / 50 Hz | |
| Max. head (m) | 8 | 12.9 |
| Max flow rate (m3/h) | 21.8 | 32.4 |
| Discharge | 2" V | |
| Free passage (mm) | 38 | |
| Weight (Kg) | 18 | 23 |
