Recommended for residential and public installations, for irrigation systems or for cleaning out wells to be desilted. Thanks to its high head, it guarantees excellent results for water features and fountains.
Fields of application:
- Clear water (spring water, pond water, fountain water...).
- Rainwater and seepage water.
- Slightly sandy water.
Specifications:
- Environmentally friendly dry motor 2900 rpm, double-impregnated winding resistant to humidity.
- Hydraulic body co-moulded with the motor casing.
- EN-GJL-250 cast iron motor casing and impeller.
- 431 stainless steel shaft.
- Double 2 SiC mechanical seal, each in an oil chamber.
- Epoxy paint, blue colour.
- Discharge, horizontal port 1"1/2.
- Protection rating: IP 68. Class F.
- Maximum operating temperature 40°C, (90°C max 3 min).
- Maximum immersion depth 20m.
- Liquid pH between 6 and 14 pH.
- Maximum motor starts per hour: 30.
| Model | AP BLUE PRO 200 AUT | AP BLUE PRO 200 M | AP BLUE PRO 2000 T |
|---|---|---|---|
| Reference | 205225 | 205226 | 205278 |
| Power (Kw) | 1.50 | ||
| Voltage (V) | 230 | 400 | |
| Frequency (Hz) | 50 | ||
| Current (A) | 7.5 | 3.2 | |
| Ø discharge Horizontal |
Threaded 1" 1/2 | ||
| Passage in (mm) | 4 | ||
| TDH (mWC) | 26 | ||
| Max flow rate (m3/h) | 19 | ||
| Float | WITH | WITHOUT | |
| Electric cable (m) | 10 | ||
| Weight (Kg) | 24 | ||
