Applications:
- For fire protection, powerful washing, pressurised irrigation, tank filling, water lifting.
Advantages:
- High pressure, reduced flow rate.
- 3-port discharge manifold, allows either two lines of 1’’ hoses that can support 4 sprinklers per line, or a single line at the discharge in 40/45 for fire protection or other applications. It is also possible to use the main DN40 outlet and a side outlet at the same time.
Engine specifications:
- Honda 4-stroke engine, 98 unleaded petrol.
- Model GX160U1.
- Low oil safety cut-out.
- Manual starter.
Pump specifications:
- Self-priming centrifugal pump
- Aluminium pump body.
- Aluminium impeller.
- Reinforced mechanical seal.
Accessories supplied with the engine-driven pump:
- With installation and maintenance instructions, CE certificate.
- 1 spark plug spanner.
- 2 ribbed fittings.
- 3 Clamps.
- 1 Strainer.
| Model | LIBRA S3 |
|---|---|
| Reference | 225189 |
| Power (CV) | 5.5 |
| Honda engine | GX 160 |
| Fuel | Unleaded petrol 98 |
| Type | 4-stroke |
| Suction |
2" |
| Delivery | 1" 1/2 |
| Max flow rate (m3/h) | 30 |
| Max. pressure (bar) | 5.5 |
| Particle size (mm) | 0.5 |
| Self-priming MAX (m) | - 7 |
| Starter | Manual |
| Tank (L) | 3.6 |
| Autonomy (h) | 2 h 20 |
| Dimensions (mm) | 540 x 420 x 480 |
| Weight (Kg) | 31.0 |
