Applications:
- Engine-driven pump for rental, fire services, abrasive liquids, emptying septic tanks.
- Pumping of water loaded with mud, sand, soil.
- Pumping of liquids loaded with solid particles up to 20 mm in diameter.
- Pump for building sites, quarries, sand pits, mines.
Specifications:
- Pump body in pressure die-cast aluminium.
- Impeller and diffuser in chrome cast iron, high resistance to abrasion.
- Silicon carbide mechanical seal.
- Inspection hatch at the front of the pump, allowing any object blocking it to be cleared very quickly.
- Tubular stainless steel transport trolley, with pneumatic tyre wheel, diameter 200 mm.
- Honda GX 200 petrol engine.
Supplied:
- With installation and maintenance instructions.
- CE certificate.
- Spark plug wrench.
- Hose fitting.
- Clamps.
- Strainer.
| Model | KTH 80 CHASSIS |
KTH 80 TROLLEY |
L-KTH 80 TROLLEY |
|---|---|---|---|
| Reference | 225325 | 225179 | 225326 |
| Power (HP) | 6.0 | 7.0 | |
| Max flow rate (m3/h) | 60 | ||
| Head (m) | 28 | 25 | |
| Max pressure (bar) | 2.8 | 2.5 | |
| Engine | GX 200 | 15LD-350 | |
| Fuel | Petrol | Diesel | |
| Max. particle size (mm) | 20 | ||
| Suction diameter/ Delivery (mm) |
barbed 75 - 3" M | ||
| Self-priming (m) | 7 | ||
| Running time (h) |
1.5 | 2h30 | |
| Dimensions (cm) | 52x70x46 | 75 x 76 x 80 | |
| Weight (Kg) | 55 | 66 | 72 |
