Uses:
- Drainage of excavations and sewers.
- Cleaning of wells and boreholes.
- Pumping of mud and bentonite
- Sewage treatment plants, septic tanks.
- Emptying of ponds and basins.
- Shipyards.
- Fire brigades.
- Floods.
Pump specifications:
- Self-priming up to 7 m.
- Can run dry without any damage.
- No mechanical part is in contact with the pumped liquid.
- Excellent resistance to abrasion and corrosion.
- Large passage for solids (28mm).
- Few wearing parts, very easily interchangeable.
- The Lib 1/2" site version is made of die-cast aluminium, which makes it light and easy to use.
- In this version, it is supplied with a reduction ratio of 1:43 (straight teeth).
Engine specifications:
- Honda GX 160 petrol engine - 5.5 Cv.
- Manual start, recoil starter.
- Low oil safety cut-out.
Advantages:
- The Libellula engine-driven pump has a flexible connecting rod for greater safety if a solid particle larger than the permissible particle size is pumped.
| Model | LIB/1-2" |
|---|---|
| Reference | 225236 |
| Petrol engine (4T) | HONDA GX160 |
| Power (HP) | 5.5 |
| Manual start | Recoil starter |
| Low oil safety cut-out | WITH |
| Inlet/outlet diameter (mm) | 2" |
| Running time (h) | 2h30 |
| Max flow rate (m3/h) | 10 |
| Max. head (m) | 10 |
| H.M.T. (m) | 15 |
| Particle size (mm) | 50 |
| Dimensions (cm) | 123 x 68 x 65 |
| Weight (Kg) | 65 |
