Applications:
- Very heavily loaded water, muddy, sandy water, sludge, bentonite.
- Thick liquids, harbour water, foundation drainage, construction sites, mines, quarries, rivers.
- Industrial waste water.
Specifications:
- Grey cast iron pump.
- Semi-vortex impeller.
- Very robust 2-pole motor.
- Agitator on the shaft end.
- Grey cast iron base plate.
- Double mechanical seal, silicon carbide and oil bath.
- Sealed ball bearings.
- Models KTV2-50U and KTV2-80U, reinforced series, special for abrasion.
| Model | KTV2-50 | KTV2-80 | KTV2-50U | KTV2-80U |
|---|---|---|---|---|
| Reference | 215316 | 215317 | 215318 | 215319 |
| Voltage (V) | TRI - 400 - (50 hz) | |||
| Power (Kw) | 2.00 | 3.00 | 2.00 | 3.00 |
| Rated current (A) | 3.8 | 6.1 | 3.8 | 6.1 |
| Max. flow rate (m3/h) | 25 | 43 | 25 | 43 |
| Max TDH (m) | 20.0 | 22.5 | 20.0 | 22.5 |
| Outlet diameter (mm) | 50 | 80 | 50 | 80 |
| Outlet | Threaded and barbed | |||
| Particle size (mm) | 8.5 | |||
| Min. pumping level (mm) | 120 | 130 | 120 | 130 |
| Max. depth (m) | 25 | |||
| Cable length (m) | 20 | |||
| Weight (Kg) | 25.0 | 38.0 | 25.0 | 38.0 |
