Applications:
- Automatic drinking water supply pump for remote sites, camper vans, boats, mobile homes, fire engine vehicle self-protection pump.
Specifications:
- Nickel-plated brass body and fittings.
- 316 stainless steel shaft.
- PTFE helical gears.
- Check valve.
- Electronic control of the motor speed according to the flow rate.
- 24 volt direct current supply.
- 2 PCS control boxes, with connector, 3 m cable (allows remote monitoring of the pump's operation and interaction with it). (Model UP6/E
+ PCS).
- Manifold on the suction and discharge sides.
| Models | UP6/E-DX | UP12/E-DX |
|---|---|---|
| Reference | 605610 | 605612 |
| PCS box | x2 | |
| Supply (V DC) | 24 | |
| Power (W) | 2 x 180 | 2 x 360 |
| Consumption (A) |
8.5 to 15 | 20 to 25 |
| Flow rate (l/min) | 0 to 52 | 0 to 72 |
| Pressure (bar) | 3.5 | |
| Priming (m) | 1.5 | 3.0 |
| Ports | 3/4" | 1" |
| Hose (mm) | 20 | 25 |
| Fuse (A) | 20 | 30 |
| Weight (Kg) | 11.0 | 16.0 |
