The pump has been designed for intermittent use; operation with the outlet closed is possible.
Applications:
- Engine oil transfer (max 85 ° C-185 ° F).
- Diesel fuel pumping.
- Transfer of viscous liquids.
- Transfer of oils, antifreeze.
- Circulation of viscous liquids.
- Draining of engine sumps.
- Fresh water transfer.
Specifications:
- 3/8" BSP ports, supplied with ribbed fittings for 13/14 mm hose.
- OT58 brass pump body.
- Bronze gear.
- Stainless steel shaft.
- Nitrile impeller.
- Sealing by lip ring.
- Suction/discharge port: 3/8" female thread.
- 12/24 V permanent magnet DC motor.
- IP 55 protection..
| Model | UP6/OIL 12 | UP6/OIL 24 |
|---|---|---|
| Reference | 605187 | 605188 |
| Voltage (V DC) | 12 | 24 |
| Power (W) | 120 | |
| Current draw (A) | 7.0 | 4.0 |
| Priming (m) | 1.5 | |
| Flow rate with Ø 6 hose (l/h) | 25 | |
| Flow rate with Ø 8 hose (l/h) | 75 | |
| Flow rate with Ø 13 hose (l/h) | 480 | |
| Hose (mm) | 12 | |
| Ports | 3/8" | |
| Weight (Kg) | 2.5 | 2.5 |
Supplied with two fittings for hoses of Ø 14mm inside + 2 fittings Ø 8mm.
