The pump has been designed for intermittent use; operation with the outlet closed is possible.
Applications:
- Engine oil transfer (max 120°C).
- Diesel fuel pumping.
- Transfer of viscous liquids.
- Transfer of oils, antifreeze.
- Circulation of viscous liquids.
- Draining of engine sumps.
- Fresh water transfer.
Specifications:
- OT58 brass pump body.
- Bronze helical gears.
- Stainless steel shaft.
- Nitrile impeller.
- Sealing by lip ring.
- Suction/discharge port: 1/2" female thread.
- 12/24 V permanent magnet DC motor.
- IP 55 protection.
- 1/2" BSP ports, supplied with ribbed fittings for 16 mm hose.
| Model | UP12/OIL 12 | UP12/OIL 24 |
|---|---|---|
| Reference | 605185 | 605186 |
| Voltage (V DC) | 12 | 24 |
| Power (W) | 180 | |
| Pressure (bar) | 3 | |
| Current draw (A) | 11 | 6 |
| Priming (-m) | 2 | |
| Flow rate with Ø 12 hose (l/h) | 360 | |
| Flow rate with Ø 16 hose (l/h) | 900 | |
| Hose (mm) | 16 | |
| Ports | 1/2" | |
| Weight (Kg) | 4.5 | 4.5 |
