Specifications:
- Frame, pump body, cover, feet and impeller in grey cast iron.
- Motor shaft in 431 stainless steel.
Paint: Bi-Epoxy 200 µm.
- Double mechanical seal in silicon carbide (2 SiC).
- VITON gaskets.
- Operation: submerged.
- Intermittent operation: S3 - 50%.
- Max number of starts per hour 30.
- IP 68 protection, class H insulation.
- Max temperature of pumped liquid +90°C.
- pH of pumped liquid between 6 and 14.
- Max immersion depth 10 m.
- Density of the pumped liquid 1100 kg/m3.
| Model | DRG 150/2/G50H A3AT5 |
|---|---|
| Reference | 215371 |
| Power (Kw) |
1.10 |
| Voltage (V) |
400 |
| Current (A) | 2.4 |
| Max flow rate (m3/h) | 40 |
| Max. head (m) |
11.5 |
| Free passage (mm) |
15 x 10 |
| Discharge |
DN32 / G 2" |
| Electric cable (m) | 10 |
| Weight (Kg) | 27.5 |
