Single-phase models
| Model | INV NEOS 3/4" |
INV JUNIOR 1" 1/4 |
INV SENIOR 1" 1/2 |
INV MASTER 2" |
|---|---|---|---|---|
| Reference | 607301 | 607302 | 607303 | 607304 |
| Power supply (V) | Single-phase 230V |
|||
| Power (Kw) | 0.25 | 0.55 | 1.10 | 1.85 |
| Speed (rpm) | 1200 to 3400 | 1200 to 3400 | 600 to 1700 | 600 to 1700 |
| Flow rate (l/min) | 10 to 34 |
13 to 60 |
50 to 150 |
90 to 250 |
| Head (m) | 18 | 18 | 20 | 20 |
| Ports |
BSP 3/4" - 20 | BSP 1" - 25 | BSP 1" 1/2 - 40 | BSP 2" - 50 |
| Weight (Kg) | 22.0 | 28.8 | 37.5 | 51.3 |
Three-phase models
| Model | INV NEOS 3/4" |
INV JUNIOR 1" 1/4 |
INV SENIOR 1" 1/2 |
INV MASTER 2" |
INV 60 stainless steel 2" |
INV 70 stainless steel 2" |
INV 80 stainless steel 2" |
|---|---|---|---|---|---|---|---|
| Reference | 607307 | 607308 | 607309 | 607310 | 607311 | 607312 | 607313 |
| Power supply (V) | Three-phase |
||||||
| Power (Kw) | 0.25 | 0.55 | 1.10 | 1.85 | 4.00 | 7.50 | 15.00 |
| Speed (rpm) | 1200 to 3400 | 1200 to 3400 | 600 to 1700 | 600 to 1700 | 600 to 1700 | 600 to 1700 | 600 to 1700 |
| Flow rate (l/min) | 10 to 34 |
13 to 60 |
50 to 150 |
90 to 250 |
150 to 400 | 215 to 570 | 356 to 979 |
| Head (m) | 18 | 18 | 20 | 20 | 30 | 35 | 40 |
| Ports |
BSP 3/4" |
BSP 1" |
BSP 1" 1/2 |
BSP 2" |
BSP 2" |
BSP 2" 1/2 |
BSP 2" |
| Weight (Kg) | 22.0 | 28.8 | 37.5 | 51.3 | 76.0 | 108.0 | 240.0 |
Use:
- Transfer of food liquids, alcohol.
- Oenology and oil sector (wine, must, vinegar and oil).
- Food sector (fruit juice, beer, syrups, brine, etc.).
- Cheese-making sector (milk, whey, etc.).
- Chemical sector (acids, solvents, photographic liquids, detergents, inks, etc.).
- Cosmetics and pharmaceutical sector.
- Agricultural sector (fungicide products, liquid fertilisers).
- Transfer of hydrocarbons, light oil.
Specifications:
- 316 stainless steel pump body and impeller.
- 316 stainless steel shaft.
- Long motor-pump coupling.
- Mechanical seal: ceramic, graphite, EPDM, other materials available: VITON, PTFE, NBR.
- Single-phase or three-phase motor depending on model.
- Speed controller in watertight box, with 15m remote control, ON/OFF buttons + motor speed adjustment potentiometer.
- Mounted on stainless steel trolley.
