Use:
- Loaded (dirty) water, loaded liquids.
Specifications:
- Cast iron pump body.
- Cast iron impeller.
- 431 stainless steel shaft.
- 2 mechanical seals (SIC).
- Insulation class H - IP 68 protection.
- Maximum liquid temperature: + 40°C.
- Maximum immersion depth: 20 metres.
- RIRN8-F power cable, length 10 metres.
- Continuous duty, with thermal protection.
| Model | Reference | P ( kW) | U (V) | I (A) | Ref H DN | Flow rate max (m3/h) | TDH (m) | Weight (Kg) |
|---|---|---|---|---|---|---|---|---|
| DGG 250/2/80 F0AT |
210477 | 1.80 | 400 | 3.7 | DN80 | 61.9 | 7.3 | 35.0 |
| DGG 300/2/80 G0ET |
210478 | 2.20 | 4.6 | 48.6 | 8.5 | 44.2 | ||
| DGG 400/2/80 H0ET |
210479 | 3.00 | 6.4 | 60.4 | 12.3 | 47.0 | ||
| DGG 550/2/80 N0FT |
210480 | 4.00 | 7.7 | 83.1 | 16.3 | 71.6 | ||
| DGG 750/2/80 A0FT |
210481 | 5.50 | 10.8 | 100.8 | 16.1 | 74.3 | ||
| DGG 1000/2/80 A0FT | 210482 | 7.50 | 13.7 | 131.4 | 20.8 | 82.2 |
