Use:
- To reduce the dangerous overvoltages that are generated in the motor cable depending on its length and that can prematurely damage the motor windings and the drive,.
- To improve motor efficiency and reduce its heating.
- To reduce electromagnetic interference in the surrounding environment.
Specifications:
- DV / DT filters: For motor cables up to 400 m (PWM 4.0 kHz).
- Operating frequency: 50-60 Hz.
- Compliance with IEC-61558-2-20.
- Insulation class: class F.
- Maximum temperature of the working environment: 40 °C.
- Ventilation: natural
- Insulation: 3kV.
| Model | 14A | 32A |
|---|---|---|
| Reference | 009249 | 009250 |
| Voltage (V) | 3 x 190 - 520 | |
| Frequency (Hz) | 50/60 | |
| Max current (A) | 14 | 32 |
| Protection | IP 23 | |
| Max. ambient temperature (°C) | 40 | |
| Cooling system |
Natural ventilation | |
