Use:
- To reduce the dangerous overvoltages that are generated in the motor cable depending on its length and that can prematurely damage the motor windings and the drive,.
- To improve motor efficiency and reduce its heating.
- To reduce electromagnetic interference in the surrounding environment.
Specifications:
- DV / DT filters: For motor cables up to 150 m (PWM 2.5 kHz).
- Operating frequency: 50-60 Hz.
- Compliance with IEC-61558-2-20.
- Insulation class: class F.
- Maximum temperature of the working environment: 40 °C.
- Ventilation: natural
- Insulation: 3kV.
| Model | 14A | 32A | 90A |
|---|---|---|---|
| Reference | 009246 | 009247 | 009248 |
| Voltage (V) | 3 x 190 - 520 | ||
| Frequency (Hz) | 50/60 | ||
| Max current (A) | 14 | 32 | 90 |
| Protection | IP 23 | ||
| Max. ambient temperature (°C) | 40 | ||
| Cooling system |
Natural ventilation | ||
