Stainless steel DC transfer pump AL (12V and 24V)

The best solution for suction and transfer of liquids, stainless steel pump body, professional series. The high priming capacity of the AL pump (direct current) makes it the ideal solution for suction and transfer of corrosive liquids (aggressive chemical liquids, chemical fertilisers, sea water) and food liquids (milk, wine, oil, fruit juice...). Able to operate with an intermittent presence of liquid at the suction. Marine, agricultural and tanker truck use...

AL pump specifications :
- 316 stainless steel pump body, impeller and shaft.
- 12 or 24 Volt direct current motor with terminal box.
- Degree of protection IP23.
- Liquid temperature up to +90 °C.
- Ambient temperature up to +40 °C.
- Maximum density: 1.1g/m3 (free of sand particles & not too viscous).
- Do not use with petrol, solvents and, in general, in places where there is a risk of explosion and fire.
- Direct current.
- Maximum suction head: 6 m.

 Customs code : 84138100 – Made in Italy.

Options:
- Stainless steel transport trolley.
- CLAM, DIN and MACON fittings.
- Straight and elbow ribbed stainless steel fittings.
- Variable speed drive.
- Ceramic/graphite/EPDM mechanical seal and EPDM O-ring (+100°C).
- Ceramic/graphite/Viton mechanical seal and Viton O-ring (+130°C).
- Silicon carbide/Viton mechanical seal and Viton O-ring (+130°C).
- Mechanical seal graphite/AISI 316/Teflon and Teflon O-ring (concentrated acids).
