Principle:
- The flexible blades of the impeller deform and draw the liquid into the pump body.
- Continuous, gentle transfer of the product (ideal for dosing, filling and filtration).
- With a pump rotation direction reverser, allowing the liquid to be sent back and the hoses to be emptied at the end of transfer, for rinsing the pump.
Advantages:
- Little shearing of the pumped product.
- Self-priming pump up to 6 m deep, even when dry.
- The pump works in any position.
- Excellent pumping at low speed (ideal for transferring delicate and fragile fluids).
- Viscosity of the pumped liquid up to 50,000 cP.
- Pumping of liquids with suspended particles without aerating, emulsifying or damaging the solid particles.
Uses:
- Transfer, filling, emptying, recycling, mixing, filtering, dosing and separation pump.
- In the wine-making sector (wine, must, destemmed grapes).
- For pharmaceutical liquids, creams, lotions, liquid soap.
- For food liquids, butter, beer, jam, compote, dessert cream, cheese, glucose, vegetable oil, fruit juice, crepe batter, fruit pulp, honey, molasses, tomato sauce, brine, syrup, sugar, wines, yoghurts.
- For chemical liquids, waxes, detergents, emulsions, glycols.
Specifications:
- Positive displacement pump with natural rubber (EPDM) rotor, or other material on request, NR, CR, NBR, or Silicone (VMQ).
- Pump body and pump cover in 316 stainless steel.
- Radio remote control.
- 420 stainless steel shaft.
- Double mechanical seal WIDIA-WIDIA-Viton / SiC-SiC-EPDM.
- Electrical cabinet with push buttons, indicator lights, frequency inverter, radio remote control, provision for level float, built-in dry-running protection.
- Transport trolley in 304 stainless steel.
- A2 stainless steel bolts.
| Models | ALL IN ONE MAJOR 5-120 MF |
ALL IN ONE MAJOR 10-200 MF |
|---|---|---|
| Reference | 607165 | 607166 |
| Power supply (V DC) | Single-phase |
|
| Power (Kw) | 2.20 | |
| Speed (rpm) | 25 to 470 | 50 to 900 |
| Flow rate (l/min) | 5 to 120 | 10 to 200 |
| Ports |
DIN 40 | DIN 50 |
| Weight (Kg) | 75.0 | 77.0 |
| Models | ALL IN ONE MAJOR 5-120 TF |
ALL IN ONE MAJOR 10-200 TF |
ALL IN ONE MAXI 20-300 TF |
ALL IN ONE MAXI 38-440 TF |
|---|---|---|---|---|
| Reference | 607167 | 607168 | 607169 | 607170 |
| Power supply (V DC) | Three-phase |
|||
| Power (Kw) | 2.20 | 4.00 | ||
| Speed (rpm) | 25 to 470 | 50 to 900 | 25 to 470 | 50 to 600 |
| Flow rate (l/min) | 5 to 120 | 10 to 200 | 20 to 300 | 38 to 440 |
| Ports |
DIN 40 | DIN 50 | DIN 50 | DIN 65 |
| Weight (Kg) | 75.0 | 77.0 | 83.0 | 88.00 |
* Other fittings (SMS, BSP F, DIN 11851, Garolla, Triclover, Friederich, RJT): please contact us.
