Limits of use:
- Liquid temperature: from 0°C to +110°C.
- Ambient temperature up to +50 °C.
- Maximum permissible pressure in the pump body: 10 bars.
- Suction head up to 7 metres
Specifications:
- Pump made entirely of 304 stainless steel.
- Mechanical seal in hard carbon/ceramic/EPDM.
- 2-pole three-phase motor 230/400 V - 50 Hz.
- Insulation class F.
- IP 55 protection.
| Model | Reference | Power (Kw) |
Voltage (V) |
Ø Suction (F) |
Ø Discharge (F) |
Weight (Kg) |
|---|---|---|---|---|---|---|
| EHX 9/2 T | 600650 | 0.75 | 230/400 three-phase |
1" 1/2 | 1" 1/4 | 11.5 |
| EHX 9/3 T | 600651 | 1.10 | 12.8 | |||
| EHX 9/4 T | 600652 | 1.50 | 13.2 | |||
| EHX 9/5 T | 600653 | 2.20 | 16.8 | |||
| EHX 9/6 T | 600654 | 17.5 | ||||
| EHX 9/7 T | 600655 | 3.00 | 18.5 | |||
| EHX 9/8 T | 600656 | 22.4 |
| Model | m3/h | 0 | 3.6 | 4.8 | 6.0 | 7.2 | 9.6 | 12.0 | 14.4 |
|---|---|---|---|---|---|---|---|---|---|
| l/min | 60 | 80 | 100 | 120 | 160 | 200 | 240 | ||
| EHX 9/2 | Height (m) |
23.5 | 21 | 21 | 20 | 19 | 16 | 12 | 4 |
| EHX 9/3 | 35.5 | 32 | 31 | 30 | 29 | 25 | 18 | 7 | |
| EHX 9/4 | 48 | 44 | 42 | 41 | 39 | 34 | 26 | 11 | |
| EHX 9/5 | 59.5 | 55 | 53 | 51 | 48 | 42 | 31 | 12 | |
| EHX 9/6 | 71 | 65 | 62 | 60 | 56 | 48 | 36 | 13 | |
| EHX 9/7 | 84 | 78 | 75 | 73 | 69 | 61 | 46 | 20 | |
| EHX 9/8 | 96 | 89 | 85 | 82 | 78 | 68 | 52 | 21 |
