Use:
- Transfer of food liquids (milk, wine, olive oil, fruit juice, etc.).
- Transfer of chemical liquids, liquid fertilisers.
Specifications:
- 316 stainless steel pump body, impeller and shaft.
- Mechanical seal of your choice depending on the model, (Ceramic-Graphite-NBR, Ceramic-Graphite-VITON, Ceramic-Graphite-EPDM).
- Suction and discharge fittings, BSP M 1", CLAMP (50.5mm), or DIN 25 Male.
- Self-priming.
- With flow reversing valve.
- Max suction head 6 m.
- BY-PASS option (on request).
| Model | Reference | Flow rate max (l/min) |
Height max (m) |
Mechanical seal | Connection |
| ALT 30 1" NBR |
605727 | 80 | 40 | NBR | BSP M 1" |
| ALT 30 1" EPDM |
605728 | EPDM | BSP M 1" | ||
| ALT 30 1" VITON |
605729 | VITON | BSP M 1" | ||
| ALT 30 CLAMP EPDM |
605730 | EPDM | CLAMP 50.5 | ||
| ALT 30 CLAMP VITON |
605731 | VITON | CLAMP 50.5 | ||
| ALT 30 DIN 25 EPDM |
605732 | EPDM | DIN 25 | ||
| ALT 30 DIN 25 VITON |
605733 | VITON | DIN 25 |
