Pedrollo NKm 2 immersed pump 230V

Pedrollo NKm 2 immersed pump 230V

506098
Delivery 2 to 4 days
€948.33

€948.33 tax excl.

rating Read the review
Average rating: 10/10 Number of reviews: 1

Pedrollo NKm 2 immersed pump 230V is ideal for wells. Without float switch. Maximum flow to 4.8m3/h.

PUISSANCE

Attributs
Image Ref. PUISSANCE Unit price Avail. Buy
Pedrollo NKm 2 immersed pump 230V
506098 0.55 Kw
€948.33
Available
Pedrollo NKm 2 immersed pump 230V
506099 0.90 Kw
€965.00
Available
Pedrollo NKm 2 immersed pump 230V
506100 1.10 Kw
€1,048.33
Available
Pedrollo NKm 2 immersed pump 230V
506101 1.10 Kw (1)
€1,098.33
Available
Pedrollo NKm 2 immersed pump 230V
506102 1.50 Kw
€1,156.67
Available
Pedrollo NKm 2 immersed pump 230V
506103 1.50 Kw (1)
€1,211.67
Available
Pedrollo NKm 2 immersed pump 230V
506105 2.20 Kw
€1,322.50
Available
Pedrollo NKm 2 immersed pump 230V
506105 2.20 Kw (1)
€1,428.33
Available
Total: 0,0
All prices with tax included.
Available Product is available
Out of stock Product is no longer in stock
Can be back-ordered Product is no in stock, but is allowed to be back-ordered
Description

Particulary suitable for the draining of clean water. Use in domestic, collective, agricultural and industrial applications. The NK pump can be connected with blowers, tanks... for irrigation system, for pumping clean water in stones wells,  tubewells, cisterns...

Characteristics immersed pumps for wells - PEDROLLO NKm 2
 Model Referency Power
(kw)		 hp
 Voltage
220-240 (V)
 Impellers Electropump DN
NKm 2/1 505 021 0.45kw 0.60 Single phase 3 PEDROLLO 1 1/4"
NKm 2/2 505 022 0.55kw 0.75 Single phase 4 PEDROLLO 1 1/4"
NKm 2/3 505 023 0.75kw 1.00 Single phase 5 PEDROLLO 1 1/4"
NKm 2/4 505 024 1.10kw 1.50 Single phase  7 PEDROLLO  1 1/4"
NKm 2/5 505 025 1.50kw 2.00 Single phase 6 PEDROLLO  1 1/4"



♦ Delivery with cable on 20m lenght + standardised datasheet electrical plug), on single phase models.
♦ Without check valve (to provide for installation).

Product Details
Supply voltage :
single phased 220 à 240 V
Protection factor :
68
Certification :
CE
Garantee :
2 years
Engine :
Inox AISI 304
Electric cable :
H07RN-F de 15m
Insulation grade :
F
Pump body :
stainless steel AISI 304
Shaft :
Inox AISI 303
Thermical protection :
Intégré au boitier d’alimentation
Pump discharge :
1" 1/4 female
Outer sleeve :
stainless steel AISI 304
Turbines and diffusers :
Inox AISI 304
Moteur :
Rebobinable
Diamètre pompe :
132 mm
Condensateur :
Dans boitier externe
Crépine d'aspiration :
Inox AISI 304
Température du liquide Maxi :
+ 40°C
Visserie :
Inox AISI 304
