CALPEDA 4SDF 22 stainless steel 4" borehole pump - 400V - 2.5 m3/h
CALPEDA 4SDF 22 stainless steel 4" borehole pump - 400V - 2.5 m3/h
CALPEDA 4SDF 22 stainless steel 4" borehole pump - 400V - 2.5 m3/h
CALPEDA 4SDF 22 stainless steel 4" borehole pump - 400V - 2.5 m3/h

CALPEDA 4SDF 22 stainless steel 4" borehole pump - 400V - 2.5 m3/h

504262
Delivery 2 to 4 days
€659.17

€659.17 tax excl.

CALPEDA 4SDF 22 stainless steel borehole pump 4", with a flow from 1.5 m3/h to 2.5 m3/h, DN100 for pumping in deep wells. NEMA standard. Power from 0.37 kw to 2.20 kw. Three-phase 400V.

PUISSANCE

Attributs
Image Ref. PUISSANCE Unit price Avail. Buy
CALPEDA 4SDF 22 stainless steel 4" borehole pump - 400V - 2.5 m3/h
504262 0.37 Kw
€659.17
Available
CALPEDA 4SDF 22 stainless steel 4" borehole pump - 400V - 2.5 m3/h
504263 0.37 Kw
€699.17
Available
CALPEDA 4SDF 22 stainless steel 4" borehole pump - 400V - 2.5 m3/h
504264 0.55 Kw
€755.00
Available
CALPEDA 4SDF 22 stainless steel 4" borehole pump - 400V - 2.5 m3/h
504265 0.75 Kw
€843.33
Available
CALPEDA 4SDF 22 stainless steel 4" borehole pump - 400V - 2.5 m3/h
504266 1.10 Kw
€997.50
Available
CALPEDA 4SDF 22 stainless steel 4" borehole pump - 400V - 2.5 m3/h
504268 1.50 Kw
€1,228.33
Available
CALPEDA 4SDF 22 stainless steel 4" borehole pump - 400V - 2.5 m3/h
504269 2.20 Kw
€1,482.50
Available
Total: 0,0
All prices with tax included.
Available Product is available
Out of stock Product is no longer in stock
Can be back-ordered Product is no in stock, but is allowed to be back-ordered
Description

Pump with floating turbines for drilling 4". Use for clean liquids, with a quantity of sand to 150g/m3 in the body pump.

Characteristics of 4SDF pump :
- CALPEDA 4" encapsulated motor (DN 100) - 2900 rpm - IP 68 (continuous service)
- Three-phase 400V - 50Hz
- CALPEDA hydraulics 4" multi-stages, (all made in stainless steel)
- impeller and diffusor in NORYL
- Maxi start-up to 20/h (at regular interval)
- Temperature of liquid until + 30°C

- In-built non-return valve.

Characteristics of CALPEDA 4SDF 22 submersible pump for drilling to 4 inches
 Model Reference Power
(kw)		 Intensity
(A)
 Voltage
400 (V)		 Stages
(nomber)
4SDF 22/4
 504 262 0.37 1.2 Three-phase 4
4SDF 22/7
 504 263 0.37 1.2 Three-phase 7
4SDF 22/10
 504 264 0.55 1.5 Three-phase 10
4SDF 22/14
 504 265 0.75 2.0 Three-phase 14
4SDF 22/18
 504 266 1.10 2.9 Three-phase 18
4SDS 22/21
 504 267 1.10 2.9 Three-phase 21
4SDF 22/28
 504 268 1.50 4.2 Three-phase 28
4SDF 22/35
 504 269 2.20 5.5 Three-phase 35
4SDF 22/42 504 270 2.20 5.5 Three-phase 42
4SDF 22/50 504 271 3.00 7.4 Three-phase 50
4SDF 22/57 504 272 3.00 7.4 Three-phase 57





Flow rate of 4SDF 22 CALPEDA pump - Discharge heighter
Flow m3/h  0.3  0.6 0.9  1.2  1.5 1.8 2.4 3 3.3
l/min 5 10 15 20 25 30 40 50 55

22/4
Total
discharge
heighter
in meter


 25.8 25.2 24.3 23.1 21.6 19.8 15.5 10.3 7.4
22/7 45.1 44 42.5 40.4 37.8 34.7 27.1 18 13
22/10 64.4 62.9 60.7 57.7 54 49.6 38.8 25.8 18.5
22/14 90.2 88.1 84.9 80.8 75.6 69.5 54.3 36.1 25.9
22/18 116 113 109 104 97.2 81.3 69.8 46.4 33.4
22/21 135 132 127 121 113 104 81.4 54.1 38.9
22/28 180 176 170 162 151 139 109 72.2 51.9
22/35 225 220 212 202 189 174 136 90.2 64.9
22/42 271 264 255 242 227 208 163 108 77.8
22/50 322 315 303 289 270 248 194 129 92.7
22/57 367 359 346 329 308 283 221 147 106
